Generating BlurHash Strings and Creating Blurred Placeholders with Node.js

In this post, we’ll explore how to generate a BlurHash string from an image and use it to create a blurred placeholder image. BlurHash is an efficient way to encode an image into a short string, which can later be decoded back into a low-quality blurred version. It’s great for improving user experiences by providing placeholders while images load.

We’ll be using the following packages:

• axios: To fetch images from URLs.
• fs: For file system operations.
• blurhash: To encode and decode images into a BlurHash.
• image-size: To determine image dimensions.
• canvas: To draw images onto a canvas and create placeholder images.

Step 1: Fetching Images

First, we need to fetch an image, whether from a URL or from the local filesystem.

async function fetchImage(url) {
  const response = await axios.get(url, { responseType: 'arraybuffer' });
  return Buffer.from(response.data);
}

Here, we use axios to fetch the image data as an arraybuffer and convert it into a Buffer.

Step 2: Extract Image Data

To process the image and create a BlurHash, we need to extract pixel data from it. We’ll use canvas for this, resizing the image if it’s larger than a specified maximum size.

async function getImageData(imageBuffer, maxSize = 512) {
  const image = await loadImage(imageBuffer);
  const scale = Math.min(maxSize / image.width, maxSize / image.height, 1);
  const width = Math.floor(image.width * scale);
  const height = Math.floor(image.height * scale);

  const canvas = createCanvas(width, height);
  const ctx = canvas.getContext('2d');
  ctx.drawImage(image, 0, 0, width, height);
  const imageData = ctx.getImageData(0, 0, width, height).data;

  return {
    data: new Uint8Array(imageData),
    width,
    height
  };
}

This function:

• Loads the image using loadImage().
• Scales the image if necessary to fit within the maxSize constraint.
• Draws the image onto a canvas and extracts the pixel data.

Step 3: Generating a BlurHash

Next, we take the pixel data and generate a BlurHash string using the blurhash library. The number of components (e.g., 4 and 3 in the encode() function) can be adjusted to control the level of detail.

async function generateBlurhash(imageSource, isUrl = false) {
  try {
    let imageBuffer;
    let width, height;

    if (isUrl) {
      imageBuffer = await fetchImage(imageSource);
    } else {
      const dimensions = sizeOf(imageSource);
      width = dimensions.width;
      height = dimensions.height;
      imageBuffer = fs.readFileSync(imageSource);
    }

    const { data, width: imgWidth, height: imgHeight } = await getImageData(imageBuffer);
    const blurhash = encode(data, imgWidth, imgHeight, 4, 3); // Adjust components as needed

    return { blurhash, imgWidth, imgHeight };
  } catch (error) {
    console.error('Error generating BlurHash:', error);
  }
}

• If isUrl is true, the image is fetched from the web; otherwise, it’s read from the local filesystem.
• The getImageData() function processes the image, and the blurhash library encodes the pixel data into a BlurHash string.

Step 4: Decoding the BlurHash to Create a Placeholder

We now take the BlurHash string and decode it into an array of pixels, which is then drawn onto a canvas to create the blurred placeholder.

function createBlurredImage(blurhash, width, height, outputPath) {
  const pixels = decode(blurhash, width, height);

  const canvas = createCanvas(width, height);
  const ctx = canvas.getContext('2d');

  const imageData = ctx.createImageData(width, height);
  imageData.data.set(pixels);

  ctx.putImageData(imageData, 0, 0);

  const out = fs.createWriteStream(outputPath);
  const stream = canvas.createPNGStream();
  stream.pipe(out);
  out.on('finish', () => {
    console.log('Blurred image saved to', outputPath);
  });
}

This function:

• Decodes the BlurHash string into pixel data.
• Draws the decoded pixels onto a canvas and saves the blurred image as a PNG file.

Example Usage

Here’s how you can put everything together and generate both the BlurHash string and the blurred image:

async function exampleGenerateBlurhash() {
  const imageSource = './mohanlal.jpg'; // Path to your local image
  const isUrl = false; // Set to true if imageSource is a URL

  const result = await generateBlurhash(imageSource, isUrl);
  if (result) {
    console.log('BlurHash:', result.blurhash);
  }
}

async function exampleCreateBlurredImage() {
  const imageSource = './mohanlal.jpg'; // Path to your local image
  const isUrl = false;
  const outputPath = './blurred-placeholder.png'; // Output file path

  const result = await generateBlurhash(imageSource, isUrl);
  if (result) {
    createBlurredImage(result.blurhash, result.imgWidth, result.imgHeight, outputPath);
  }
}

exampleGenerateBlurhash();
exampleCreateBlurredImage();

In this example:

• We first generate the BlurHash string using exampleGenerateBlurhash().
• Then, we create a blurred placeholder image using exampleCreateBlurredImage().

const fs = require('fs');
const axios = require('axios');
const { encode, decode } = require('blurhash');
const sizeOf = require('image-size');
const { createCanvas, loadImage } = require('canvas');

// Fetch image from URL
async function fetchImage(url) {
  const response = await axios.get(url, { responseType: 'arraybuffer' });
  return Buffer.from(response.data);
}

// Extract image data
async function getImageData(imageBuffer, maxSize = 512) {
  const image = await loadImage(imageBuffer);

  // Resize if the image is larger than maxSize
  const scale = Math.min(maxSize / image.width, maxSize / image.height, 1);
  const width = Math.floor(image.width * scale);
  const height = Math.floor(image.height * scale);

  const canvas = createCanvas(width, height);
  const ctx = canvas.getContext('2d');
  ctx.drawImage(image, 0, 0, width, height);
  const imageData = ctx.getImageData(0, 0, width, height).data;

  return {
    data: new Uint8Array(imageData),
    width,
    height
  };
}

// Generate blur hash
async function generateBlurhash(imageSource, isUrl = false) {
  try {
    let imageBuffer;
    let width, height;

    if (isUrl) {
      // Handle network image
      imageBuffer = await fetchImage(imageSource);
    } else {
      // Handle local file
      const dimensions = sizeOf(imageSource);
      width = dimensions.width;
      height = dimensions.height;
      imageBuffer = fs.readFileSync(imageSource);
    }

    const { data, width: imgWidth, height: imgHeight } = await getImageData(imageBuffer);

    // Encode the image data to BlurHash
    const blurhash = encode(data, imgWidth, imgHeight, 4, 3); // Adjust components as needed

    return { blurhash, imgWidth, imgHeight };
  } catch (error) {
    console.error('Error generating BlurHash:', error);
  }
}

// Create a blurred placeholder image from a blur hash
function createBlurredImage(blurhash, width, height, outputPath) {
  // Decode the blur hash
  const pixels = decode(blurhash, width, height);

  // Create a canvas and draw the decoded image
  const canvas = createCanvas(width, height);
  const ctx = canvas.getContext('2d');

  // Create an ImageData object and set the pixel data
  const imageData = ctx.createImageData(width, height);
  imageData.data.set(pixels);

  // Draw the image data onto the canvas
  ctx.putImageData(imageData, 0, 0);

  // Save the canvas as an image file
  const out = fs.createWriteStream(outputPath);
  const stream = canvas.createPNGStream();
  stream.pipe(out);
  out.on('finish', () => {
    console.log('Blurred image saved to', outputPath);
  });
}

// Example usage of functions

// Generate blur hash from a local image or URL
async function exampleGenerateBlurhash() {
  const imageSource = './mohanlal.jpg'; // Path to your local image
  const isUrl = false; // Set to true if imageSource is a URL

  const result = await generateBlurhash(imageSource, isUrl);
  if (result) {
    console.log('BlurHash:', result.blurhash);
    // Optionally save the blur hash to a file or database
  }
}

// Create a blurred placeholder image from a blur hash
async function exampleCreateBlurredImage() {
  const imageSource = './mohanlal.jpg'; // Path to your local image
  const isUrl = false; // Set to true if imageSource is a URL
  const outputPath = './blurred-placeholder.png'; // Output file path

  const result = await generateBlurhash(imageSource, isUrl);
  if (result) {
    createBlurredImage(result.blurhash, result.imgWidth, result.imgHeight, outputPath);
  }
}

// Run the example functions
exampleGenerateBlurhash();
exampleCreateBlurredImage();

Conclusion

In this tutorial, we’ve covered how to generate a BlurHash string from an image and use it to create a blurred placeholder image. This technique is useful for improving user experience by showing a preview while the original image loads.
